Mastering the JN0-660 - Foundations and Interior Gateway Protocols

The Juniper Networks Certified Professional, Service Provider Routing and Switching (JNCIP-SP) certification is a significant milestone for any network engineer working in the service provider industry. The corresponding exam, JN0-660, is designed to validate a deep level of understanding and skill in handling complex service provider network technologies. Passing this exam demonstrates an engineer's proficiency in advanced routing protocols, virtual private network services, and class of service implementations. This series is crafted to provide a comprehensive guide to the topics covered, helping candidates prepare thoroughly for the challenges presented in the JN0-660 test. The JN0-660 exam is not for beginners. It assumes a solid foundation of knowledge, typically validated by the JNCIA-Junos and JNCIS-SP certifications. The scope of the exam is broad, covering everything from the intricate workings of Interior Gateway Protocols (IGPs) like OSPF and IS-IS to the global scale of Border Gateway Protocol (BGP). Furthermore, it delves into the enabling technologies for modern services, such as MPLS, Layer 3 VPNs, Layer 2 VPNs, and the critical mechanisms of Class of Service (CoS). This initial part will focus on building the foundational knowledge of IGPs required to succeed. Success in the JN0-660 exam requires more than just theoretical knowledge. It demands practical, hands-on experience and a nuanced understanding of how these different technologies interact within a large-scale service provider network. The exam questions are often scenario-based, pushing candidates to apply their knowledge to solve real-world problems. Therefore, the goal of this series is not just to list facts but to explain the concepts in a way that builds a strong mental model of a Junos-based service provider infrastructure. We will begin by exploring the foundational IGPs, which form the bedrock upon which more complex services are built.

The Strategic Value of the JN0-660 in a Career

Achieving the JNCIP-SP certification by passing the JN0-660 exam is a clear indicator of professional expertise. For individuals, it opens doors to senior engineering roles, architectural positions, and specialized operational tasks within service provider environments. It validates that an engineer can not only configure and manage but also troubleshoot and optimize a complex network. This level of certification is highly respected in the industry and can lead to significant career advancement and increased earning potential. It sets a professional apart from those with more fundamental certifications, marking them as a specialist in the service provider domain. For organizations, having JNCIP-SP certified engineers on staff provides immense value. It ensures that the team possesses the necessary skills to design, deploy, and maintain robust and scalable network services. This expertise translates into higher network availability, faster service deployment, and more efficient troubleshooting, which are all critical for a service provider's success. Companies often invest in training their staff for the JN0-660 because they understand the direct return on investment through a more capable and efficient engineering team. A certified professional brings a standardized level of excellence and best practices to the organization's network operations.

OSPF Deep Dive for Service Providers

Open Shortest Path First (OSPF) is a fundamental link-state Interior Gateway Protocol that is extensively tested in the JN0-660 exam. In a service provider context, OSPF is often used as the underlying IGP to provide reachability for BGP next-hops and for MPLS label distribution protocols like LDP and RSVP. Its hierarchical design, using areas, makes it scalable for large networks. A key concept is the Designated Router (DR) and Backup Designated Router (BDR) election on multi-access segments, which reduces the number of adjacencies and the volume of Link-State Advertisement (LSA) flooding, a crucial optimization in dense networks. Understanding the OSPF database, known as the Link-State Database (LSDB), is critical. Each router within an area maintains an identical copy of the LSDB for that area. This database is a collection of LSAs, which are descriptive packets containing information about routers, links, and network reachability. The Shortest Path First (SPF) algorithm, also known as Dijkstra's algorithm, is then run against this database to calculate the shortest path to every destination. This process results in a loop-free topology. For the JN0-660, candidates must be proficient in analyzing the LSDB to troubleshoot routing issues. The configuration of OSPF on Junos devices is a practical skill you will need. This includes setting up interfaces in specific areas, configuring router IDs, and manipulating cost metrics to influence path selection. Authentication is another important aspect, ensuring that only authorized routers can form adjacencies and exchange routing information. The JN0-660 exam expects candidates to be comfortable with both clear-text and MD5 authentication methods. A thorough grasp of these configuration elements is essential for building and securing the IGP foundation of a service provider network.

Understanding OSPF Area Types

The concept of areas is central to OSPF's scalability, and the JN0-660 requires a detailed understanding of different area types. The backbone area, Area 0, is the core of the OSPF network. All other areas must connect to Area 0, either directly or through a virtual link. This design ensures that inter-area routing information can be properly propagated throughout the OSPF domain. An Area Border Router (ABR) is a router that connects one or more areas to the backbone area and is responsible for summarizing routing information. Standard areas, or non-backbone areas, carry a full link-state database for their own area, default routes, and summary routes for other areas. However, to further optimize routing and reduce the LSDB size on routers, special area types were introduced. A stub area is a prime example. Routers in a stub area do not receive external routes (Type 5 LSAs) from other OSPF areas or from other routing protocols. Instead, the ABR injects a single default route into the stub area, simplifying the routing table for internal routers. For even greater optimization, there are Totally Stubby Areas and Not-So-Stubby Areas (NSSA). A Totally Stubby Area, a Cisco proprietary concept but important to understand conceptually, blocks both external (Type 5) and inter-area summary (Type 3) LSAs, receiving only a default route from the ABR. The JN0-660 focuses on standard implementations, such as NSSA. An NSSA allows an area to have its own Autonomous System Boundary Router (ASBR) and import external routes, which are propagated as Type 7 LSAs. These Type 7 LSAs are then translated into Type 5 LSAs by the NSSA ABR for distribution to the rest of the OSPF domain.

A Closer Look at OSPF Link-State Advertisements (LSAs)

Proficiency with OSPF LSAs is non-negotiable for the JN0-660 exam. LSAs are the building blocks of the OSPF LSDB, and each type has a specific purpose. The Router LSA (Type 1) is generated by every router and describes its directly connected links and their states within a single area. These LSAs are only flooded within the area they originate from. The Network LSA (Type 2) is generated by the Designated Router (DR) on a multi-access network segment. It lists all the routers attached to that specific segment, and like Type 1 LSAs, its flooding is confined to its local area. Inter-area routing is handled by Summary LSAs. The ABR generates the Network Summary LSA (Type 3) to advertise prefixes from one area to another. This is how routers learn about destinations outside their own area. The ASBR Summary LSA (Type 4) is also generated by the ABR. Its purpose is to advertise the location of an Autonomous System Boundary Router (ASBR) to other areas, so routers know how to reach it. Understanding the distinction between these summary LSAs and how they enable the hierarchical design of OSPF is crucial for troubleshooting inter-area connectivity issues. External routes, which are redistributed into OSPF from another routing protocol, are carried by External LSAs (Type 5). These are generated by the ASBR and are flooded throughout the entire OSPF domain, except for stub areas. In the context of an NSSA, external routes are introduced using the NSSA External LSA (Type 7). This special LSA type is flooded only within the NSSA and is then translated into a Type 5 LSA by the NSSA ABR to be propagated to the rest of the network. A deep understanding of LSA types is key to diagnosing complex OSPF routing problems on the JN0-660.

Advanced OSPF Features for the JN0-660

Beyond the basics, the JN0-660 exam delves into more advanced OSPF features that are common in service provider networks. One such feature is route summarization, which is performed on ABRs and ASBRs. Summarization helps to reduce the size of routing tables and the LSDB in other areas, improving stability and convergence time. By consolidating multiple specific prefixes into a single, less-specific summary route, it minimizes the impact of link flaps in one area on the rest of the network. Candidates should be able to configure and verify OSPF summarization effectively. Another key advanced topic is the use of virtual links. While best practice dictates that all areas should connect directly to the backbone (Area 0), this is not always physically possible. A virtual link is a tunnel configured between two ABRs through a non-backbone transit area, making it appear as if the disjointed area is directly connected to the backbone. While they solve a specific design problem, virtual links add complexity and are generally considered a temporary or last-resort solution. For the JN0-660, you must know how and when to configure them, as well as their limitations. OSPF authentication is critical for security. The exam requires knowledge of how to configure different authentication types to prevent unauthorized routers from joining the OSPF domain and injecting malicious routes. Simple password (plain-text) authentication is available but not recommended, while MD5 authentication provides a much higher level of security by using a shared key to create a message digest. Junos also supports more granular authentication settings per interface. Being able to secure the OSPF domain is a fundamental skill for any service provider engineer and a testable topic on the JN0-660.

Introduction to IS-IS for Service Providers

Intermediate System to Intermediate System (IS-IS) is the other major IGP featured on the JN0-660 blueprint. While OSPF is very common in enterprise networks, IS-IS has a strong foothold in large service provider backbones due to its scalability and flexibility. Developed for the OSI protocol stack, it was later adapted to route IP, a version often referred to as Integrated IS-IS. Unlike OSPF, which is based on IP, IS-IS runs directly on top of the Layer 2 data-link layer. This makes it independent of the IP protocol, and it can natively support routing for different network layer protocols, including IPv6. IS-IS organizes the network into a two-level hierarchy, similar in concept to OSPF's backbone and non-backbone areas. Routers are designated as either Level 1 (L1), Level 2 (L2), or Level 1/2 (L1/L2). L1 routers handle routing within a specific area. L2 routers form a backbone and are responsible for routing between areas. An L1/L2 router acts as a border router, connecting an L1 area to the L2 backbone. This design allows for massive scalability, as the L1 routers only need to know their local area topology and a default route to the nearest L1/L2 router. One of the key advantages of IS-IS often cited in service provider circles is its use of Type-Length-Value (TLV) fields for carrying information. This makes the protocol inherently extensible. New features and information can be added to the protocol by defining new TLVs without needing to change the fundamental protocol structure. This extensibility has made it easy to adapt IS-IS for modern technologies like MPLS Traffic Engineering and IPv6. The JN0-660 exam requires candidates to have a solid grasp of IS-IS fundamentals, its hierarchical structure, and its advantages in a service provider environment.

IS-IS Levels, Adjacencies, and Areas

Understanding the IS-IS hierarchy is fundamental for the JN0-660. A router's level determines the type of adjacencies it can form. A Level 1 router can only form an adjacency with another Level 1 or a Level 1/2 router within the same area. It maintains a Level 1 Link-State Database (LSDB) which contains detailed topology information only for its own area. To reach destinations outside its area, an L1 router uses a default route pointing to the closest L1/L2 router. This simplifies routing and reduces the processing and memory overhead on L1 routers. Level 2 routers form the backbone of the IS-IS domain. They can form adjacencies with other L2 or L1/L2 routers, regardless of their area ID. They maintain a Level 2 LSDB that contains the topology information for the backbone and the prefixes reachable in each area. This L2 backbone is responsible for all inter-area routing. An IS-IS domain must have a contiguous L2 backbone for full reachability, much like OSPF requires a contiguous Area 0. The scalability of IS-IS comes from this clear separation of intra-area and inter-area routing. A Level 1/2 router is the bridge between the levels. It maintains both an L1 LSDB for its area and an L2 LSDB for the backbone. It forms L1 adjacencies with other routers in its area and L2 adjacencies with other backbone routers. The L1/L2 router is responsible for advertising routes from its L1 area into the L2 backbone, and for injecting a default route into the L1 area so that internal routers can reach external destinations. For the JN0-660, you must be able to design, configure, and troubleshoot this two-level hierarchy.

Comparing OSPF and IS-IS for the JN0-660 Exam

While both OSPF and IS-IS are link-state IGPs that use Dijkstra's algorithm to calculate shortest paths, the JN0-660 expects you to know their key differences. A major distinction is their transport mechanism. OSPF runs on top of IP (protocol number 89), meaning it requires a functioning IP stack to operate. IS-IS, on the other hand, communicates directly over Layer 2. This makes IS-IS independent of the network layer protocol and is one reason for its smooth integration of IPv6 support. This difference also affects how neighbors are discovered and how adjacencies are formed. Another key comparison point is their hierarchical design. OSPF uses a strict two-level hierarchy centered around the backbone Area 0. All other areas must connect to this backbone. IS-IS also uses a two-level hierarchy with Level 1 for intra-area routing and Level 2 for inter-area routing. However, the IS-IS design is arguably more flexible. The L2 backbone is simply the collection of all L2-capable routers, which can be located in any area. This can sometimes simplify network design and expansion compared to the rigid Area 0 requirement of OSPF. From an extensibility perspective, IS-IS is often considered superior due to its use of TLVs. OSPF has required more significant protocol changes, such as the development of OSPFv3 for IPv6, to add new capabilities. IS-IS was able to add support for new technologies like traffic engineering by simply defining new TLVs. In a large service provider network where new features and services are constantly being deployed, this extensibility is a significant advantage. For the JN0-660, be prepared to compare and contrast these protocols based on scalability, design, and operational characteristics in a service provider context.

The Role of BGP in Service Provider Networks

Border Gateway Protocol (BGP) is the cornerstone of the global internet and a paramount topic for the JN0-660 certification. Unlike Interior Gateway Protocols such as OSPF or IS-IS, which are designed for routing within a single Autonomous System (AS), BGP is an Exterior Gateway Protocol (EGP) designed for routing between different Autonomous Systems. In a service provider network, BGP is used to exchange reachability information with other service providers, enterprise customers, and content delivery networks. Its primary function is not to find the fastest path, but to enforce routing policy based on business relationships. The JN0-660 exam requires a deep understanding of BGP's function and operation. This includes the distinction between Internal BGP (IBGP) and External BGP (EBGP). EBGP sessions are established between routers in different Autonomous Systems, for example, between two service providers. IBGP sessions are established between routers within the same AS. This is necessary because once an EBGP route is learned, it must be propagated to all other BGP-speaking routers within the local AS to ensure consistent routing and to avoid routing loops. We will explore the mechanics of this propagation later. At its core, BGP is a path-vector protocol. When a BGP router advertises a prefix, it includes a list of Autonomous Systems that the route has traversed to reach its current location. This list is known as the AS_PATH attribute. This path information is the primary mechanism for loop prevention. If a router receives a BGP update that contains its own AS number in the AS_PATH, it knows the route has looped and will discard the update. Understanding this fundamental behavior is essential for mastering BGP for the JN0-660.

BGP Path Attributes and the Selection Process

The power of BGP lies in its rich set of path attributes, which are used to describe and influence routes. The JN0-660 demands a thorough knowledge of these attributes and how they are used in the BGP route selection algorithm. Attributes are categorized into four types: well-known mandatory, well-known discretionary, optional transitive, and optional non-transitive. Well-known attributes must be recognized by all BGP implementations, while optional attributes may not be. Transitive attributes are passed along to other BGP peers, while non-transitive attributes are not. Some of the most critical attributes tested on the JN0-660 include AS_PATH, NEXT_HOP, and ORIGIN. The AS_PATH, as mentioned, is a mandatory list of AS numbers a route has traversed. The NEXT_HOP attribute indicates the IP address of the next-hop router to reach the advertised prefix. The ORIGIN attribute indicates how the route was introduced into BGP, with IGP being preferred over EGP, which is preferred over INCOMPLETE. These three form the basic set of information needed for a BGP route. Other influential attributes include the Local Preference (LOCAL_PREF), Multi-Exit Discriminator (MED), and Communities. LOCAL_PREF is a well-known discretionary attribute used within an AS to choose a preferred exit point for outbound traffic. A higher LOCAL_PREF value is always preferred. MED is an optional non-transitive attribute used to influence how a neighboring AS sends traffic to your AS. A lower MED value is preferred. Communities are an optional transitive attribute used to tag routes with specific identifiers, which can then be used to apply a common policy. Mastering how these attributes interact is key to passing the JN0-660.

The BGP Route Selection Algorithm

The BGP route selection process is a deterministic, step-by-step algorithm that every BGP router uses to decide which path is the best for a given prefix when it learns multiple paths from different peers. The JN0-660 exam will test your understanding of this process in detail. The algorithm is executed for each prefix in the BGP routing table. The first check is to ensure that the NEXT_HOP for the route is reachable. If the next-hop is not valid or reachable in the router's main routing table (inet.0), the route is not considered for selection. Once next-hop reachability is confirmed, the algorithm proceeds through a series of steps. It starts by preferring the route with the highest LOCAL_PREF. This is a crucial step for controlling outbound traffic flow within an AS. If the LOCAL_PREF values are equal, the router will then prefer routes that it originated itself. Following this, it will prefer the route with the shortest AS_PATH. This step seeks the path that has traversed the fewest Autonomous Systems, which is often, but not always, an indicator of a better path. If all previous checks result in a tie, the process continues. The next step is to evaluate the ORIGIN code, preferring IGP over EGP over INCOMPLETE. If a tie still exists, the path with the lowest MED value is chosen, but this is typically only compared among routes received from the same neighboring AS. The algorithm continues with several more steps, including preferring EBGP over IBGP paths, preferring the path through the closest IGP neighbor, and finally using router IDs as a tie-breaker. Knowing this sequence is vital for predicting BGP behavior on the JN0-660.

BGP Peering: IBGP vs. EBGP

The distinction between Internal BGP (IBGP) and External BGP (EBGP) is fundamental. EBGP sessions are formed between routers in different AS numbers. These sessions are typically established over direct physical connections, and the Time-to-Live (TTL) value of the BGP packets is, by default, set to 1 to enforce this. However, for multihop EBGP sessions where peers are not directly connected, the TTL must be explicitly increased. EBGP is how routing information is exchanged between service providers and their customers or peers. IBGP sessions, on the other hand, are formed between routers within the same AS. The purpose of IBGP is to ensure that all BGP routers within an AS have a consistent view of the external routes learned via EBGP. A critical rule for IBGP is its split-horizon behavior: a route learned from one IBGP peer will not be advertised to another IBGP peer. This rule prevents routing loops within the AS. To overcome this, all IBGP routers within an AS must be fully meshed, meaning every IBGP router must peer with every other IBGP router. This full-mesh requirement for IBGP presents a significant scalability challenge. In an AS with 'n' routers, the number of IBGP sessions required is n*(n-1)/2. As the network grows, the number of sessions and the associated configuration and processing overhead becomes unmanageable. The JN0-660 exam requires candidates to understand solutions to this scaling problem, namely BGP Route Reflection and BGP Confederations. These techniques allow for the distribution of IBGP routes without requiring a full mesh of peering sessions, making the network far more scalable and easier to manage.

Implementing BGP Routing Policies

BGP is not primarily about finding the shortest path; it is about policy. A service provider must be able to control which routes it accepts, which routes it advertises, and which paths it prefers for both inbound and outbound traffic. The JN0-660 exam heavily emphasizes the implementation of routing policy. In Junos OS, this is achieved through a powerful policy framework using policy-statements. These statements consist of terms that match on routes based on specific criteria and then apply actions to those matched routes. Policies are applied at various points, most commonly when importing routes into the BGP table from a peer (import policy) or when exporting routes from the BGP table to a peer (export policy). For example, an import policy could be used to filter out unwanted prefixes from a customer or to set the LOCAL_PREF on routes learned from a specific peer to influence the exit point. An export policy might be used to prevent the advertisement of certain internal routes to the internet or to prepend the AS_PATH to make a path less attractive to a neighbor. The Junos policy language is rich and flexible. It allows matching on a wide range of criteria, including prefixes (using prefix-lists), AS_PATHs (using as-path regular expressions), and communities. Actions can include accepting or rejecting a route, modifying attributes like LOCAL_PREF or MED, or adding, removing, or modifying community tags. A deep, practical understanding of how to construct and apply these policies is absolutely essential for success on the JN0-660, as many questions will be scenario-based, requiring you to determine the correct policy to achieve a desired outcome.

Scaling IBGP with Route Reflection

As discussed, the full-mesh requirement of IBGP does not scale well in large networks. The primary solution to this problem is BGP Route Reflection. A Route Reflector (RR) is a BGP router that is allowed to break the IBGP split-horizon rule. It can reflect routes learned from one IBGP peer to its other IBGP peers. The peers of an RR are known as its clients. The RR and its clients form a cluster. This design dramatically reduces the number of required IBGP sessions. Instead of every router peering with every other router, each client only needs to peer with the Route Reflector. For redundancy, it is common to deploy multiple Route Reflectors within a network. In this case, the Route Reflectors themselves must be fully meshed to ensure they have a complete and consistent set of routes to reflect to their clients. The JN0-660 expects you to understand the rules of route reflection. A route learned from an EBGP peer can be reflected to all clients. A route learned from an IBGP client peer can be reflected to all other clients and also to any non-client IBGP peers. A route learned from a non-client IBGP peer can only be reflected to clients. To prevent loops within a route reflection topology, two special BGP attributes are used: ORIGINATOR_ID and CLUSTER_LIST. The ORIGINATOR_ID is an optional, non-transitive attribute created by the RR that carries the router ID of the BGP speaker that originally injected the prefix into the cluster. If a router receives a reflected route with its own router ID as the ORIGINATOR_ID, it will discard the route. The CLUSTER_LIST contains a list of cluster IDs that the route has traversed. If an RR receives a route that already contains its own cluster ID, it will discard it.

Scaling IBGP with Confederations

Another method for solving the IBGP full-mesh scalability problem is BGP Confederations. This approach involves dividing a large Autonomous System into multiple smaller, private sub-ASes. Within each of these sub-ASes, a standard full mesh of IBGP sessions or route reflection is configured. EBGP sessions are then configured between the different sub-ASes. From the perspective of the outside world, the entire collection of sub-ASes appears as a single, large AS. The private AS numbers used within the confederation are stripped from the AS_PATH when routes are advertised to true external peers. Confederations are generally considered more complex to design and implement than route reflection and are less commonly deployed in modern networks. However, they are still part of the JN0-660 curriculum. The main advantage is that they can provide better isolation and more granular policy control between different parts of a large AS. Each sub-AS can be managed independently, with its own IGP and IBGP topology. The EBGP peering between sub-ASes behaves like standard EBGP, but with some special considerations for attributes like NEXT_HOP, MED, and LOCAL_PREF. When deciding between route reflection and confederations, most network designers today choose route reflection for its relative simplicity and ease of deployment. It allows for a single, unified IGP and a simpler logical topology. Confederations might be considered in very large, complex networks that have been built through mergers or acquisitions, where logically separating parts of the network into their own sub-AS might make administrative sense. For the JN0-660, you should understand the mechanics of both methods and be able to compare their use cases.

Advanced BGP Features and Troubleshooting

The JN0-660 exam will test your knowledge of more advanced BGP features that are crucial in service provider environments. One such feature is BGP Multipath, which allows a router to install and use multiple equal-cost BGP paths to the same destination in its forwarding table. This enables load balancing across different links and can improve overall network utilization and resiliency. You must understand the conditions that must be met for BGP to consider paths as equal and eligible for multipath. Another important topic is BGP route damping. This is a mechanism used to reduce the instability caused by frequently flapping routes. When a route is repeatedly withdrawn and re-advertised, BGP can apply a penalty to it. If the penalty exceeds a certain threshold, the route is suppressed, or "damped," for a period of time, even if it becomes available again. This prevents widespread routing instability from propagating across the internet. You should be familiar with the configuration parameters for route damping and its potential drawbacks, such as delaying reconvergence for legitimate routes. Finally, troubleshooting BGP is a core skill. For the JN0-660, you must be proficient with Junos operational mode commands to check the state of BGP sessions (show bgp summary), inspect the routes received from a peer (show route receive-protocol bgp <neighbor>), the routes being advertised to a peer (show route advertising-protocol bgp <neighbor>), and the details of a specific prefix in the BGP table (show route table inet.0 protocol bgp <prefix> extensive). Being able to trace the flow of BGP updates and interpret the output of these commands is critical for diagnosing and solving complex BGP problems.

Introduction to MPLS Fundamentals

Multiprotocol Label Switching (MPLS) is a foundational technology for modern service provider networks and a core component of the JN0-660 exam. MPLS is a forwarding mechanism that directs data from one network node to the next based on short path labels rather than long network addresses, avoiding complex lookups in a routing table at every hop. This technique speeds up traffic forwarding and, more importantly, provides a powerful platform for traffic engineering and the creation of virtual private networks (VPNs). It operates at a layer that is generally considered to lie between Layer 2 (Data Link Layer) and Layer 3 (Network Layer). The core components of an MPLS network are Label Switching Routers (LSRs). An LSR is a router that is capable of understanding and forwarding MPLS packets. When an IP packet enters an MPLS domain at an Ingress Label Edge Router (LER), the router performs a routing lookup, assigns a label to the packet based on its destination, and forwards it to the next hop. Subsequent LSRs in the path, known as transit routers, simply swap the incoming label for an outgoing label and forward the packet. This label swapping process continues until the packet reaches the Egress LER, which removes the label and forwards the original IP packet to its final destination. The path that an MPLS-labeled packet follows is called a Label Switched Path (LSP). LSPs are unidirectional, meaning that for two-way communication, two separate LSPs are required, one for each direction. The establishment of these LSPs is managed by a label distribution protocol. For the JN0-660, you need to be intimately familiar with the two primary protocols used for this purpose: the Label Distribution Protocol (LDP) and the Resource Reservation Protocol with Traffic Engineering extensions (RSVP-TE). Each has its own mechanism for distributing labels and establishing paths, and they serve different use cases within the service provider network.

Label Distribution Protocol (LDP)

LDP is the most common and straightforward protocol used to distribute labels in an MPLS network. Its primary function is to automatically discover MPLS-enabled neighbors and establish sessions to exchange label information. LDP works in conjunction with an Interior Gateway Protocol (IGP) like OSPF or IS-IS. The IGP is responsible for determining the network topology and calculating the shortest path to all destinations. LDP then uses this information to build LSPs that follow the paths determined by the IGP. This is often referred to as IGP-driven MPLS forwarding. When LDP is enabled on a router's interfaces, it starts sending out Hello messages to discover other LDP-speaking neighbors on the same link. Once two routers discover each other, they attempt to establish an LDP session over a TCP connection. After the session is established, they begin exchanging label mappings for all the prefixes in their routing tables. Each router will assign a unique local label for each prefix and advertise this label-to-prefix binding to its LDP neighbors. This process results in the creation of a complete set of LSPs across the network. A key concept in LDP is the Forwarding Equivalence Class (FEC). A FEC is a group of IP packets that are forwarded in the same manner, over the same path, and with the same forwarding treatment. In the context of LDP, all packets destined for the same IP prefix typically belong to the same FEC. Each LSR assigns one label for each FEC. For the JN0-660, you must understand how to configure and verify LDP operations, including session establishment, label advertisement, and how LDP builds the label forwarding table (mpls.0 in Junos).

Resource Reservation Protocol (RSVP-TE)

While LDP is excellent for creating LSPs that follow the IGP's shortest path, service providers often need more granular control over how traffic is routed through their network. This is where the Resource Reservation Protocol with Traffic Engineering extensions (RSVP-TE) comes in. RSVP-TE allows network administrators to explicitly define the paths that LSPs should take, independent of the IGP's calculated shortest path. This is known as traffic engineering, and it is a critical topic for the JN0-660. Unlike LDP, which automatically builds LSPs for all prefixes, RSVP-TE is used to signal and establish specific, explicitly routed LSPs. The administrator defines the LSP's path as a series of strict or loose hops. RSVP then signals this path from the ingress LER to the egress LER, reserving resources like bandwidth along the way. Path messages are sent downstream from ingress to egress to request the path, and Resv messages are sent upstream from egress to ingress to confirm the reservation and distribute the labels. This process creates a traffic-engineered LSP. RSVP-TE provides capabilities far beyond simple path control. It can be used to establish primary and secondary backup paths for fast reroute, to enforce bandwidth constraints, and to select paths based on administrative colors or affinities. To support these features, the underlying IGP (typically OSPF or IS-IS) needs to have traffic engineering extensions enabled. These extensions allow the IGP to flood additional link attribute information, such as available bandwidth and link colors, which RSVP-TE can then use to make more intelligent path computation decisions. A solid grasp of RSVP-TE configuration and operation is essential.
