Mastering the E20-393 Exam: Foundational Concepts of Dell EMC Unity

The E20-393 Exam, known as the Unity Implementation Engineer Specialist Exam, was designed for professionals responsible for the deployment, configuration, and management of Dell EMC Unity and UnityVSA storage systems. Passing this exam validated an individual's expertise in handling the core tasks associated with a Unity environment, from initial setup to advanced storage provisioning and data protection. This certification was a benchmark for demonstrating proficiency in one of the industry's leading midrange storage solutions. It signified that an engineer possessed the necessary skills to ensure the storage infrastructure operates efficiently, securely, and reliably to meet business requirements.

Preparing for the E20-393 Exam requires a comprehensive understanding of both the hardware and software components of the Unity platform. The exam questions typically covered a wide range of topics, including system installation, network configuration, storage allocation for block and file access, and the implementation of local and remote data protection features. Candidates were expected to be familiar with not only the graphical user interface of Unisphere but also the command-line interface for scripting and automation. A successful candidate would be able to translate customer needs into a functional and optimized Unity storage configuration, making this a critical credential for storage administrators and implementation specialists.

While certification paths evolve, the knowledge domains covered by the E20-393 Exam remain fundamentally important for anyone working with modern storage systems. The principles of storage architecture, network integration, provisioning, and data protection are timeless. Therefore, studying the topics associated with this exam provides a robust foundation in storage engineering. This series will delve deep into these core areas, providing the detailed information needed to master the concepts, whether for passing the E20-393 Exam or for excelling in a storage implementation role today. The skills honed through this preparation are directly transferable to current and future storage technologies.

This first part of our series will focus on the foundational building blocks of the Dell EMC Unity platform. We will explore the architecture, the key hardware and software elements, and the primary management interfaces. By establishing a strong understanding of these fundamentals, you will be well-equipped to tackle the more advanced topics of configuration, provisioning, and data protection covered in subsequent parts. A solid grasp of the basics is the first and most critical step towards success in the E20-393 Exam and in practical, real-world storage management scenarios.

The Role of a Unity Implementation Engineer

A Unity Implementation Engineer is a specialist tasked with the successful deployment of Dell EMC Unity storage solutions. The responsibilities of this role extend far beyond simply racking and stacking hardware. The engineer must conduct thorough site assessments, understand customer workload requirements, and design a configuration that aligns with performance, capacity, and availability goals. This includes planning for network integration, host connectivity, and data migration strategies. The skills tested in the E20-393 Exam are a direct reflection of these real-world responsibilities, emphasizing practical application over purely theoretical knowledge. An effective engineer ensures a smooth transition to the new storage platform with minimal disruption.

During the implementation phase, the engineer performs the physical installation, which involves setting up the Disk Processor Enclosure (DPE) and any additional Disk Array Enclosures (DAEs). They are responsible for proper cabling for power, management, and data networks. Following the physical setup, the engineer executes the initial configuration using the Connection Utility and the configuration wizard. This process includes setting system time, licensing, network addresses for the storage processors, and creating the Unisphere management user accounts. Meticulous attention to detail during this stage is crucial, as errors can lead to significant issues later, a key concept for the E20-393 Exam.

Once the system is online, the implementation engineer’s focus shifts to storage provisioning and host integration. This involves creating storage pools, configuring RAID protection levels, and carving out LUNs for block storage or creating file systems for NAS access. The engineer works with server and network administrators to establish connectivity via Fibre Channel or iSCSI and to ensure hosts can correctly identify and access the allocated storage. They must also implement best practices for multipathing to ensure high availability and load balancing. These tasks represent a significant portion of the E20-393 Exam blueprint.

Finally, a key responsibility is the setup of data protection services. This includes configuring local protection with snapshots and clones, as well as setting up remote replication for disaster recovery purposes. The engineer must understand the different replication technologies available, such as native asynchronous and synchronous replication, and implement the solution that best meets the customer's Recovery Point Objective (RPO) and Recovery Time Objective (RTO). The E20-393 Exam thoroughly tests a candidate's ability to configure and manage these critical business continuity features, solidifying the engineer's role as a trusted advisor for data resiliency.

Understanding Dell EMC Unity Architecture

The Dell EMC Unity architecture is built on a modern, unified platform designed for simplicity, performance, and flexibility. At its core, the system utilizes a dual-controller, active-active architecture, meaning both Storage Processors (SPs) are actively servicing I/O requests. This design enhances performance and provides inherent high availability. If one SP fails, the other seamlessly takes over its workload, a process known as non-disruptive failover. The E20-393 Exam requires a deep understanding of this fundamental architectural principle, as it underpins many of the platform's features, from software upgrades to fault tolerance.

The software environment of Unity is based on a Linux foundation, which provides a robust and stable operating platform. This is a significant evolution from previous generation systems. The Unity Operating Environment (OE) integrates block, file, and VMware VVols capabilities into a single cohesive system. The file services are handled by 64-bit NAS servers that run within the OE, providing a highly scalable and efficient file-serving solution. This unified approach simplifies management by allowing administrators to provision and manage all storage types from a single interface, Unisphere. A key focus of the E20-393 Exam is the interaction between these block and file components.

Another critical architectural element is the multi-core optimization of the software. The Unity OE is designed to take full advantage of the multiple processor cores available in modern Intel CPUs used in the SPs. The system intelligently distributes data services, such as I/O processing, data reduction, and replication, across the available cores. This parallel processing capability allows the system to deliver high performance even under heavy workloads and with advanced data services enabled. Understanding how these services are managed and their potential impact on performance is essential for success on the E20-393 Exam and for proper system tuning.

The architecture also includes an integrated approach to storage pooling and dynamic tiering. Storage pools are aggregations of physical drives from which storage resources are provisioned. Within these pools, Unity can implement Fully Automated Storage Tiering (FAST), which automatically moves data between different tiers of storage (e.g., Flash, SAS, NL-SAS) based on its activity level. This optimizes performance by placing the most active data on the fastest drives while maximizing capacity with more cost-effective drives. The E20-393 Exam will test your knowledge of how to create and manage these pools and tiering policies effectively.

Core Hardware Components of Unity

To succeed in the E20-393 Exam, a detailed knowledge of the Unity hardware components is non-negotiable. The primary building block of a physical Unity array is the Disk Processor Enclosure (DPE). The DPE houses the two Storage Processors (SPs), which are the brains of the system. It also contains the initial set of drives for the system, which can be either 2.5-inch or 3.5-inch form factors depending on the model. The DPE provides power, cooling, and the midplane that connects all the internal components, making it the foundational chassis of the entire storage array.

Each Storage Processor is a self-contained server node running the Unity Operating Environment. An SP includes multi-core Intel processors, a significant amount of RAM for caching, and multiple I/O connectivity options. Inside each SP, there is an M.2 SATA solid-state device that holds a copy of the operating system image, ensuring fast boot times and system recovery. The SPs also feature built-in ports for management, replication, and host connectivity. These can include 10Gbase-T ports, Converged Network Adapters (CNAs) that can be configured for Fibre Channel or Ethernet, and SAS ports for backend expansion.

For capacity expansion beyond the DPE, Disk Array Enclosures (DAEs) are used. DAEs are connected to the DPE via SAS cables in a redundant configuration known as a SAS backend. This ensures that there is no single point of failure in the connectivity between the SPs and the expansion shelves. DAEs come in various configurations, such as a 2U 25-drive enclosure for 2.5-inch drives or a 3U 15-drive enclosure for 3.5-inch drives. Understanding the rules and best practices for cabling these DAEs is a practical skill frequently tested on the E20-393 Exam.

I/O Modules are another critical hardware component that provides flexible host connectivity. These modules are installed in available slots on the Storage Processors and offer a variety of port types. Options typically include 16Gb/s Fibre Channel modules, 10Gb/s and 25Gb/s Ethernet modules for iSCSI and NAS, and SAS modules for host connectivity in specific use cases. The ability to select and configure the appropriate I/O modules allows the Unity system to be tailored to the specific needs of the customer's environment. The E20-393 Exam expects candidates to know which modules are available and how to configure them for different protocols.

The UnityVSA and its Purpose

The UnityVSA, or Unity Virtual Storage Appliance, is a software-defined storage solution that packages the Dell EMC Unity Operating Environment into a virtual machine. It provides the full functionality of a physical Unity array, including unified block and file storage, snapshots, replication, and data reduction, all running on a customer's existing VMware ESXi server infrastructure. The E20-393 Exam includes topics on UnityVSA because it is a key part of the Unity family, offering a flexible deployment option for various use cases. It allows organizations to leverage their investment in virtualization and standard server hardware.

One of the primary use cases for UnityVSA is for test and development environments. It allows developers and administrators to provision storage and test features like snapshots and replication without needing dedicated physical storage hardware. This accelerates development cycles and provides a safe sandbox for training and experimentation. For the E20-393 Exam, you should understand the resource requirements for deploying a UnityVSA, such as the necessary vCPUs, memory, and datastore capacity, as these are critical for a stable and performant virtual appliance.

Another important application of UnityVSA is in remote office or branch office (ROBO) scenarios. In these environments, deploying a full physical array might be cost-prohibitive or operationally complex. The UnityVSA can be deployed on a single server to provide robust, enterprise-grade storage services for smaller workloads. When combined with native replication, data from multiple ROBO locations can be replicated back to a central physical Unity array at a primary data center for backup and disaster recovery. This hub-and-spoke model is a powerful architecture that an implementation engineer should know how to design and configure.

The UnityVSA is also an excellent tool for disaster recovery. A physical Unity array at a production site can replicate its data to a UnityVSA running at a secondary DR site. This provides a cost-effective DR solution, as it avoids the need for a second identical physical array. In the event of a disaster, the workloads can be failed over to the DR site, and the UnityVSA will serve the data. The E20-393 Exam may present scenarios that require you to determine the best use case for a UnityVSA versus a physical array and to understand the steps involved in its deployment and configuration.

Introduction to Unisphere Management

Unisphere is the web-based graphical user interface (GUI) used to manage Dell EMC Unity storage systems. It is designed with a focus on simplicity and ease of use, providing a modern HTML5 interface that requires no Java plugins. For the E20-393 Exam, proficiency in Unisphere is absolutely essential, as it is the primary tool for nearly all configuration, management, and monitoring tasks. The dashboard provides a high-level overview of the system's health, capacity utilization, and performance, allowing administrators to quickly assess the state of their storage environment at a glance.

The navigation in Unisphere is organized logically around key storage objects. Menus for Storage, Access, Protection & Mobility, and Service provide intuitive pathways to configure the respective system functions. For example, under the Storage menu, you can manage pools, LUNs, file systems, and VMware datastores. The Access menu is where you configure hosts, initiators, and networking. This task-oriented layout helps administrators quickly find the settings they need without navigating through complex and confusing menu trees. An E20-393 Exam candidate should be able to navigate this interface efficiently to perform specific configuration tasks under time pressure.

One of the powerful features of Unisphere highlighted in the E20-393 Exam curriculum is its proactive assistance and integrated online help. The interface includes wizards for common tasks like initial configuration, storage provisioning, and replication setup. These wizards guide the administrator step-by-step through the process, ensuring all necessary parameters are configured correctly. Additionally, Unisphere provides context-sensitive help and links to online documentation and knowledgebase articles directly within the interface. This helps reduce the learning curve and empowers administrators to resolve issues independently.

Beyond configuration, Unisphere offers robust monitoring and reporting capabilities. It provides real-time and historical performance charts for various system components, including SPs, LUNs, and file systems. Administrators can create custom dashboards to monitor the specific metrics that are most important to their environment. The system also features a comprehensive alerting system that can notify administrators of potential issues via email or SNMP traps. Understanding how to use these tools to monitor health and troubleshoot performance problems is a critical skill for an implementation engineer and a key topic for the E20-393 Exam.

Key Concepts for Exam Success

To achieve success on the E20-393 Exam, it is crucial to move beyond rote memorization and develop a deep conceptual understanding of the Unity platform. One of the most important concepts is the distinction and interaction between the block and file components of the unified system. You must understand how Storage Processors handle I/O for LUNs versus how NAS servers manage client access to file systems. This includes knowing the different network protocols involved (iSCSI/FC for block, NFS/SMB for file) and how they are configured within Unisphere. The exam will test your ability to apply these concepts in practical scenarios.

Another key concept is dynamic pooling. Unlike traditional RAID groups, Unity's dynamic pools offer greater flexibility and efficiency. You must understand how drives are organized into private RAID extents within a pool and how this architecture allows for easy expansion and faster drive rebuilds. Familiarize yourself with the process of creating a pool, selecting drive types and RAID widths, and understanding the implications of these choices on performance and capacity. The E20-393 Exam will expect you to know the best practices for pool design to meet different workload requirements.

High availability and data integrity are central themes of the E20-393 Exam. This means you need a solid grasp of how the active-active controller architecture, multipathing, and redundant components work together to prevent downtime. You should also understand the various data integrity features built into the system, such as background data scrubbing and checks to prevent silent data corruption. Being able to articulate how Unity ensures data is both available and correct is fundamental to demonstrating your expertise as an implementation engineer.

Finally, a comprehensive understanding of the data services ecosystem is essential. This includes not just snapshots and replication but also data reduction technologies like compression and deduplication. You should know when and how to enable these features, their potential performance impact, and the benefits they provide in terms of storage efficiency. The E20-393 Exam will likely present scenarios where you need to decide which data services are appropriate for a given application or business requirement. A holistic view of how these features work together is a hallmark of a proficient Unity specialist.

Initial Planning for Unity Deployment

Thorough planning is the most critical phase for a successful Dell EMC Unity deployment and a key area of focus for the E20-393 Exam. Before any hardware is unboxed, an implementation engineer must gather detailed information about the customer's environment and requirements. This includes understanding the applications that will use the storage, their performance profiles (IOPS, throughput, latency), and their capacity growth projections. This information will dictate the choice of Unity model, the types and number of drives, and the necessary I/O modules. Neglecting this step can lead to a system that is either underpowered or over-provisioned, resulting in wasted resources or poor performance.

Network planning is another vital component of the pre-deployment phase. The engineer must work with the network administration team to allocate IP addresses for the storage system's management ports, iSCSI interfaces, and NAS server interfaces. For Fibre Channel environments, a SAN topology review is necessary to ensure proper zoning and fabric compatibility. The E20-393 Exam often includes questions that test your knowledge of network best practices, such as isolating storage traffic on dedicated VLANs or physical switches and ensuring redundant network paths for high availability. A clear and documented network plan prevents configuration errors and connectivity issues during setup.

Physical site planning is also crucial. The implementation engineer must verify that the data center has adequate space, power, and cooling to accommodate the Unity array and any expansion shelves. This involves checking rack U-space, power distribution unit (PDU) capacity, and available power outlets. The engineer should also confirm the availability of the correct types and lengths of network and SAS cables. The E20-393 Exam emphasizes the practical aspects of implementation, so understanding these logistical requirements is just as important as knowing the software configuration. A well-prepared site ensures a smooth and efficient physical installation process.

Finally, data migration planning cannot be overlooked. If the new Unity system is replacing an older storage array, a detailed plan for migrating data with minimal downtime is essential. The engineer must evaluate the available migration tools and methodologies, whether they are host-based (like LVM mirroring or Storage vMotion) or array-based. Understanding the customer's maintenance windows and business constraints is key to scheduling the migration activities. The ability to formulate a safe and effective migration strategy is a hallmark of an experienced implementation specialist and a concept you should be prepared for in the E20-393 Exam.

Physical Installation and Cabling Best Practices

Once the planning phase is complete, the physical installation of the Dell EMC Unity system begins. This process starts with securely mounting the Disk Processor Enclosure (DPE) and any accompanying Disk Array Enclosures (DAEs) into the equipment rack. It is important to follow standard data center safety procedures and best practices for lifting and handling heavy equipment. The E20-393 Exam expects candidates to be familiar with the hardware, including the location of mounting rails, cable management arms, and status indicators. Proper installation ensures system stability and allows for safe and easy service access in the future.

Cabling is a meticulous process where attention to detail is paramount. Power cabling requires connecting the redundant power supplies in both the DPE and DAEs to separate Power Distribution Units (PDUs) to protect against a PDU or circuit failure. For network connectivity, management ports should be connected to the management network, while data ports (Fibre Channel or Ethernet) should be connected to the corresponding storage network switches. The E20-393 Exam will test your understanding of which ports are used for which functions and the importance of connecting redundant ports on each Storage Processor to separate physical switches for high availability.

Backend SAS cabling, which connects the DPE to the DAEs for capacity expansion, has a very specific and mandatory topology. The SAS ports on the SPs are used to create redundant chains, or buses, of DAEs. It is critical to follow the official Dell EMC cabling diagrams precisely to ensure both SPs have a path to every drive in the system. Incorrect SAS cabling can lead to the system not recognizing the expansion shelves, or worse, creating a single point of failure. The E20-393 Exam often includes diagrams or scenario questions to test your ability to identify correct and incorrect backend cabling configurations.

After all cables are connected, cable management becomes the final step of the physical installation. Using the provided cable management arms and straps to neatly route and secure all power, network, and SAS cables is not just for aesthetics. Proper cable management improves airflow, which is critical for system cooling and longevity. It also prevents cables from being accidentally disconnected or damaged during routine data center maintenance. Demonstrating knowledge of these professional best practices is part of what the E20-393 Exam is designed to validate in a certified implementation engineer.

The Initial Configuration Wizard

After the physical installation is complete and the system is powered on, the first interaction with the Unity software is through the Initial Configuration Wizard. This wizard is accessed via a web browser by connecting a laptop to the service port or by discovering the new system on the network using the Connection Utility. The E20-393 Exam requires a thorough understanding of this process, as it is the foundational step for bringing the storage array online. The wizard provides a guided, step-by-step procedure to configure the essential system parameters.

The first stages of the wizard involve accepting the license agreement and changing the default administrative passwords. Setting strong, unique passwords for the admin and service user accounts is a critical first step in securing the system. The wizard then prompts the user to configure the system's network settings. This includes assigning a static IP address, subnet mask, and gateway for the management interface of the Unity array. Correctly configuring these settings is essential for ongoing management of the system via the Unisphere interface. An error here could make the system inaccessible over the management network.

Next, the wizard guides you through the configuration of DNS and NTP (Network Time Protocol) servers. Providing reliable DNS servers allows the system to resolve hostnames, which is important for features like sending email alerts. Configuring NTP is equally critical, as it synchronizes the system's clock with an authoritative time source. Accurate timekeeping is essential for consistent log files, accurate timestamping of snapshots, and proper functioning of authentication protocols like Kerberos. The E20-393 Exam stresses the importance of these supporting network services for a healthy storage environment.

The final steps of the Initial Configuration Wizard involve licensing and setting up ESRS (EMC Secure Remote Services) for support. The license file, obtained from Dell EMC, unlocks the full feature set of the purchased Unity system. Configuring ESRS establishes a secure, encrypted connection back to Dell EMC support, enabling proactive monitoring, remote diagnostics, and automated alert dispatching. Understanding how to enable and configure ESRS is a key competency for an implementation engineer, as it greatly enhances the supportability of the system, a topic you can expect to see on the E20-393 Exam.

Configuring Network Services for Unity

Beyond the initial setup, a robust network configuration is fundamental to the operation of a Dell EMC Unity system. This involves more than just the management IP address. The E20-393 Exam delves into the configuration of interfaces for data access, including iSCSI, NAS, and replication. For iSCSI, dedicated Ethernet ports on the I/O modules must be configured with IP addresses on the storage network. Best practices dictate using a separate, non-routable subnet for iSCSI traffic to ensure performance and security. Additionally, configuring Jumbo Frames (MTU of 9000) on the Unity ports, network switches, and host initiators can significantly improve iSCSI performance.

For file storage, the engineer must create and configure NAS Servers. A NAS Server is a logical entity within Unity that handles file sharing protocols like NFS and SMB (CIFS). Each NAS Server requires at least one network interface, which is assigned an IP address on the client access network. For high availability, multiple interfaces can be configured and aggregated using Link Aggregation Control Protocol (LACP). The E20-393 Exam will test your knowledge of how to create a NAS Server, join it to an Active Directory domain for SMB authentication, and configure its network interfaces for resilient client connectivity.

Replication traffic also requires careful network planning. The Unity system uses dedicated Ethernet ports for native asynchronous and synchronous replication between two arrays. These replication interfaces should be configured on a network that has sufficient bandwidth and low latency to meet the desired Recovery Point Objective (RPO). For security, it is a best practice to isolate replication traffic from host and management traffic using separate VLANs or physical networks. A candidate for the E20-393 Exam should be able to describe the network requirements for different replication types and how to configure the corresponding interfaces in Unisphere.

Finally, managing the system's overall network health is an ongoing task. Unisphere provides tools to view the status of all network ports, monitor their throughput, and diagnose connectivity issues. An implementation engineer should be familiar with these tools and know how to troubleshoot common network problems, such as a misconfigured switch port, an IP address conflict, or a physical layer issue. The ability to systematically diagnose and resolve network problems is a practical skill that the E20-393 Exam is designed to validate, ensuring certified professionals can maintain a stable and reliable storage network infrastructure.

Understanding iSCSI and Fibre Channel Setup

Providing block storage access to hosts is a primary function of the Dell EMC Unity platform, and the E20-393 Exam covers this topic in great detail. The two main protocols for block access are iSCSI and Fibre Channel (FC). iSCSI transmits SCSI commands over standard TCP/IP networks, making it a cost-effective and flexible option. Setting up iSCSI involves configuring the Ethernet ports on the Unity I/O modules with IP addresses for the iSCSI network. On the host side, an iSCSI initiator (either software or a hardware-based HBA) is required to discover and log in to the iSCSI targets presented by the Unity array.

Fibre Channel, on the other hand, is a dedicated, high-speed network protocol specifically designed for storage traffic. It requires a specialized infrastructure, including FC Host Bus Adapters (HBAs) in the servers and FC switches to form a storage area network (SAN). On the Unity system, FC I/O modules provide the physical ports to connect to the SAN fabric. A key concept for the E20-393 Exam is SAN zoning. Zoning is configured on the FC switches to control which host HBAs (initiators) are allowed to communicate with which Unity FC ports (targets). This is a critical security and stability measure in a SAN environment.

Regardless of the protocol used, the concept of multipathing is essential for high availability and performance. Multipathing software, such as PowerPath or the native multipathing drivers in operating systems, allows a host to have multiple active paths to the same storage device (LUN). If one path fails (e.g., a cable is disconnected, an HBA fails, or a switch port goes down), I/O can continue seamlessly over the remaining paths. The E20-393 Exam requires a thorough understanding of how to configure both the Unity array and the host for a redundant, multipathed setup to avoid any single points of failure in the storage path.

In Unisphere, the configuration process for both iSCSI and FC involves registering the hosts and their initiators with the Unity system. For FC, the initiator's World Wide Name (WWN) is used for identification. For iSCSI, the initiator's IQN (iSCSI Qualified Name) is used. Once a host is registered, it can be granted access to specific LUNs through a process often called LUN masking. This ensures that a host can only see and access the storage that has been explicitly assigned to it, preventing unauthorized access and potential data corruption. Mastering this host access configuration workflow is fundamental for the E20-393 Exam.

Managing Host Access and Initiators

Effectively managing host access is a critical security and operational function for any storage administrator, and it is a core competency tested by the E20-393 Exam. After the physical and network connectivity is established, the Dell EMC Unity system needs to be told which servers are allowed to access which storage resources. This process begins with registering the host's initiators in Unisphere. Initiators are the endpoints on the host side that originate SCSI commands; for Fibre Channel, this is the World Wide Name (WWN) of the HBA, and for iSCSI, it is the iSCSI Qualified Name (IQN).

Once the initiators are known to the Unity system, they are associated with a host object. A host object in Unisphere is a logical container that represents a physical or virtual server. It groups together all the initiators from that server, simplifying management. For example, a server with two FC HBAs and two iSCSI NICs would have all four of its initiators registered and grouped under a single host object. The E20-393 Exam will expect you to understand this object relationship and how to create and manage host objects efficiently.

After a host object is created, the next step is to grant it access to storage. In a Unity environment, this is done by presenting LUNs (Logical Unit Numbers) to the host. When a LUN is presented, the Unity system essentially makes it visible to the initiators associated with that host object. This is a form of LUN masking, which is a fundamental SAN security practice. It ensures that Server A cannot see the LUNs assigned to Server B, even if they are connected to the same SAN fabric or IP network. The E20-393 Exam often has questions about the correct procedure to provision a LUN and grant host access.

For environments with many hosts, such as a large VMware vSphere cluster, managing access on a host-by-host basis can be cumbersome. To simplify this, Unity supports the use of host groups, which are known as Consistency Groups in some contexts. By placing multiple hosts into a group, you can grant access to a LUN or a set of LUNs to the entire group in a single operation. This is especially useful for clustered applications where all nodes in the cluster need access to the same shared storage. Knowing when and how to use host groups is a key management skill tested in the E20-393 Exam.

Securing the Unity Environment

Security is a paramount concern in any IT infrastructure, and the Dell EMC Unity platform includes multiple features to protect the system and the data it stores. A core topic of the E20-393 Exam is understanding and implementing these security controls. The first line of defense is securing management access. This includes using strong, complex passwords for all user accounts, especially the default admin and service accounts. It is also a best practice to configure role-based access control (RBAC) by creating specific user roles with limited privileges, such as a "Storage Operator" who can provision storage but not change system settings.

Network security is another critical layer. As discussed, storage traffic for iSCSI and replication should be isolated on dedicated VLANs or physical networks to prevent unauthorized snooping or interference. For management access via Unisphere and SSH, the management network should be firewalled and restricted. Unity also supports configuring IP address filtering for management access, allowing you to create a whitelist of specific IP addresses or subnets that are permitted to connect to the management interface. The E20-393 Exam will test your knowledge of these network hardening techniques.

Data-at-rest encryption (D@RE) provides a powerful layer of security for the physical media. Unity systems can be equipped with self-encrypting drives (SEDs). With D@RE enabled, all data written to the drives is automatically encrypted by the drive's hardware. An internal or external key manager is used to manage the encryption keys. This ensures that if a drive is physically stolen from the data center, the data on it remains unreadable. Understanding the benefits of D@RE and the high-level steps to enable it is an important concept for the E20-393 Exam.

For file services, securing access to SMB and NFS shares is essential. For SMB, this is primarily achieved by integrating the NAS Server with a Microsoft Active Directory domain. This allows you to use standard Windows NTFS permissions to control which users and groups can access files and folders. For NFS, access can be controlled using host-based export rules and, in more advanced configurations, Kerberos for user authentication. The E20-393 Exam expects a certified professional to be proficient in configuring these file-level security settings to protect sensitive data.

Preparing for E20-393 Exam Configuration Scenarios

The E20-393 Exam is not just about knowing facts; it is about applying knowledge to solve real-world problems. Therefore, the exam is likely to feature scenario-based questions that require you to act as the implementation engineer. A typical scenario might describe a customer environment and ask you to determine the most appropriate configuration. For example, you might be given a set of application requirements and asked to design a storage pool, choosing the correct drive types and RAID protection to meet the specified performance and availability goals.

To prepare for these scenarios, it is essential to move beyond the "what" and understand the "why" behind each configuration choice. Don't just memorize the steps to create a LUN; understand why you would choose a thick LUN versus a thin LUN for a particular database application. Don't just know how to set up replication; understand the difference between asynchronous and synchronous replication and when each is the appropriate choice based on the customer's RPO and RTO requirements. The E20-393 Exam will test this deeper, decision-making level of understanding.

Hands-on practice is the most effective way to prepare for configuration scenarios. If you have access to a physical Unity lab, use it extensively. If not, the UnityVSA (Virtual Storage Appliance) is an invaluable tool. Deploy a UnityVSA in your own virtual environment and practice all the tasks covered in the exam blueprint. Go through the initial configuration, set up iSCSI and FC connectivity (using virtual hosts), create LUNs and file systems, and configure snapshots and replication. This practical experience will solidify your knowledge and build the confidence needed to tackle the exam's practical questions.

Finally, think about troubleshooting. The E20-393 Exam may present you with a scenario where a configuration is not working as expected and ask you to identify the likely cause of the problem. For example, a host cannot see its storage. You should be able to mentally run through a troubleshooting checklist: Is the physical cabling correct? Are the switch ports configured properly? Is the SAN zoning correct? Are the host's initiators registered on the Unity array? Has the LUN been presented to the correct host? Having a systematic troubleshooting methodology is a critical skill for both the exam and for your career as an implementation engineer.

Mastering Block Storage Provisioning

Block storage is the foundation of many critical enterprise applications, such as databases and virtual server infrastructures. A deep understanding of block storage provisioning on a Dell EMC Unity system is therefore a mandatory skill for passing the E20-393 Exam. Block storage provides raw volumes of storage to a host, which the host's operating system then formats with its own file system. The primary protocols used to deliver block storage are Fibre Channel and iSCSI. The provisioning process begins with the creation of a storage pool, which is a collection of physical drives managed as a single entity.

Once a storage pool is available, the next step is to create a Logical Unit Number, or LUN. A LUN is a numbered logical disk that is carved out of the storage pool's capacity. When you create a LUN, you must define its size and assign it a name. A critical decision at this stage is whether to create a thick or a thin LUN. A thick LUN pre-allocates all of its requested capacity from the pool immediately. A thin LUN, on the other hand, allocates space on demand as data is written. The E20-393 Exam will test your knowledge of the use cases and implications of each choice.

The properties of a LUN can be further customized to meet specific application requirements. For instance, you can assign a LUN to a specific tiering policy within a pool that contains multiple drive types. A "Start High then Auto-Tier" policy will initially place all data on the highest performance tier and then demote colder blocks over time. This is ideal for workloads that benefit from an initial burst of performance. The E20-393 Exam requires candidates to understand how these policies work and how to select the appropriate one for a given scenario.

After the LUN is created and configured, the final step in provisioning is to provide host access. As covered previously, this involves associating the LUN with a specific host or host group. This process, often called LUN masking or presentation, ensures that only the authorized servers can see and access the LUN. In a VMware environment, the LUN will appear as a new datastore to the ESXi hosts, ready to be formatted with VMFS. A candidate for the E20-393 Exam must master this entire workflow, from pool creation to LUN presentation, to be successful.

Creating and Managing LUNs

The process of creating and managing LUNs is a day-to-day task for a storage administrator and a central theme of the E20-393 Exam. In Unisphere, this process is streamlined through an intuitive wizard. When creating a LUN, you must provide essential information such as a name, a description, the storage pool it will reside in, and its size. An important consideration is the LUN ID. While Unity can automatically assign this, some operating systems or clustered applications have specific requirements for LUN IDs, so manual assignment is sometimes necessary.

A key decision during LUN creation is the provisioning type: thick versus thin. Thick LUNs provide predictable performance because all space is allocated upfront, eliminating the latency associated with on-demand allocation. They are often recommended for performance-sensitive applications like high-transaction databases. Thin LUNs, conversely, offer greater storage efficiency by only consuming space from the pool as data is written. This is ideal for environments where capacity is uncertain or for maximizing the utilization of the storage pool. The E20-393 Exam will test your ability to weigh these trade-offs and choose the appropriate provisioning type.

Once a LUN is created, its capacity can be managed over its lifecycle. A LUN can be expanded if more space is needed, and this operation can typically be performed online without disrupting host access. However, shrinking a LUN is often a more complex process and may require host-level tools and data migration. Therefore, proper initial sizing and the use of thin provisioning are important strategies. The E20-393 Exam expects you to know the capabilities and limitations of LUN size management within the Unity environment.

Beyond capacity, other LUN properties can be managed. You can migrate a LUN from one storage pool to another, for example, to move it from a hybrid pool to an all-flash pool for better performance. You can also manage host access, changing which hosts are permitted to see the LUN. Additionally, you can configure data protection for the LUN by creating snapshot schedules or setting up replication. A comprehensive understanding of the LUN object's lifecycle and all its configurable attributes is essential for any aspiring candidate for the E20-393 Exam.

Advanced LUN Features and Properties

Beyond basic creation and sizing, Dell EMC Unity offers advanced LUN features that are important to understand for the E20-393 Exam. One such feature is Host I/O Limits, also known as Quality of Service (QoS). This allows an administrator to set limits on the IOPS, bandwidth, or both, that a host can consume from a specific LUN. This is particularly useful in multi-tenant environments or for preventing a single, non-critical application from consuming all the storage performance, an issue sometimes referred to as the "noisy neighbor" problem.

Another advanced concept is the relationship between LUNs and Consistency Groups. A Consistency Group is a collection of LUNs that are managed as a single entity, particularly for data protection purposes. When you take a snapshot of a Consistency Group, you get a single point-in-time, application-consistent copy of all the LUNs within that group. This is critical for applications like databases that spread their data, logs, and indexes across multiple LUNs. The E20-393 Exam will expect you to know why Consistency Groups are necessary and how to configure them for multi-LUN applications.

The concept of LUN mobility is also a key feature. Using native LUN migration tools within Unisphere, you can move a LUN between different storage pools on the same Unity array non-disruptively. This might be done to rebalance capacity, to move a workload to a pool with a different performance profile, or to evacuate a pool before decommissioning drives. Understanding the process and prerequisites for LUN migration is a practical skill that a certified implementation engineer should possess and is a relevant topic for the E20-393 Exam.

Finally, understanding how data services interact with LUNs is crucial. When you enable data reduction (compression and/or deduplication) on a pool, all LUNs within that pool can benefit from the capacity savings. The E20-393 Exam requires you to understand that compression is applied inline as data is written, providing immediate space savings. You should also be familiar with how to monitor the data reduction savings for a particular LUN or for the pool as a whole. This knowledge is key to designing and managing a storage-efficient environment.
